DVD Player Function Specifications |
DESCRIPTION |
MODEL |
| AVPhile 713-K |
AVPhile 715-K |
|
|
| Dual- focus optical pickup with high accuracy |
|
| Dual- focus optical pickup with high accuracy |
|
| Disk Format |
| Audio CD |
| Video CD 1.1, 2.0 |
| Interactive VCD 3.0 |
| Super Video CD (SVCD) |
| DVD Navigation 1.0 |
| MPEG Layer 3 |
|
| Audio CD |
| Video CD 1.1, 2.0 |
| Interactive VCD 3.0 |
| Super Video CD (SVCD) |
| DVD Navigation 1.0 |
| MPEG Layer 3 |
|
| Karaoke Function (option) |
Echo/Delay/Digital Key-Shift |
Echo/Delay/Digital Key-Shift |
| Video Compression |
Supports MPEG-1 & MPEG-2 system |
Supports MPEG-1 & MPEG-2 system |
| Video Output Type |
| Composite Video Output *1 |
| Y Pb Pr componect analog output (option) |
| Scart A/V output (option) |
|
| Composite Video Output *1 |
| Y Pb Pr componect analog output (option) |
| Scart A/V output (option) |
|
| Video Resolution |
27MHz 10 bits |
27MHz 10 bits |
| Video Output |
| NTSC/PAL selection |
| Pan & Scan and Letter - Box conversions |
|
| NTSC/PAL selection |
| Pan & Scan and Letter - Box conversions |
|
| Trick Modes |
Slow, Fast Forward, Fast Reverse, Step, Goto |
Slow, Fast Forward, Fast Reverse, Step, Goto |
| Sub - Picture |
Independent Sub - Picture Decoder |
Independent Sub - Picture Decoder |
| OSD |
8 - bit On - Screen Display |
8 - bit On - Screen Display |
| Audio Processing |
| Dolby Digital (AC - 3) 5.1 or 2 - channel
downmix audio output for Dolby Prologic |
| MPEC audio up to 7.1 channel |
| DTS Digital Output |
|
| 2 - channel downmix audio output for Dolby
Prologic |
| DTS Digital Output |
|
|
| Digital Audio Output |
S/PDIF (IEC 958) : option |
S/PDIF (IEC 958) : option |
| Audio Format |
96kHz, 24 bit |
96kHz, 24 bit |
| Audio DAC |
96kHz, 24 bit |
96kHz, 24 bit |
| Interface |
Loader (DCI interface)/ ATAPI interface |
Loader (DCI interface)/ ATAPI interface |
| Power Requirement |
100VAC - 230 VAC |
100VAC - 230 VAC |
| Dimension |
434 x 95 x 290mm |
434 x 95 x 290mm |
| Weight |
4.3 kg |
4.3 kg |
| Power Consumption |
34 W |
34 W |
| |
|
|
